Outlet Threads : 21a (INT-12P)
Inlet Threads : 1) Type 4, Size 2 : 25.4 - 14 TPI, 2) Type 1, Size 2 : ¾ - 14 NGT
Valve Body Material : Brass
Working Pressure : 204 kgf/cm²
Bursting Pressure : 325 kgf/cm²
Yield Temperature : 125 ± 10°C
Gas / Mixture of Gas : CNG
Standard : IS 3224 : 2021
Design Classification : O-Ring Gland Seal Valve
Hand-Wheel Material : Plastic (unbreakable)
